Explore the Union RV 17.6HT images

• Dual Axle
• Hot dipped galvanised 150mm x 50mm x 4mm chassis
• Hot Dipped galvanised 100mm x 50mm x 4mm chassis
• CRUISEMASTER D035 V3Plus Trailer Coupling
• ARK X0750 Jockey Wheel
• Heavy Duty Independent suspension  included
• 12" Electric Brakes with Break away system
• 5 x 16 inch Alloy Wheels – 6 stud (Optional spare rear wheel)
• 265/75R16 Mud Terrain Tyres

TARE

Approx 2800KG

BALL

240KG **

ATM

3500KG**

PAYLOAD

700KG

CABIN LENGTH

7.5m

OVERALL HEIGHT

2990m with aircon

WIDTH

2.2m

• Electric Awning with poles & light
• Composite Aluminium Body panel
• Fully Enclosed Annexe
• External Hot Water Shower + Side
• Externally Mounted Ensuite Tent on non awning side
• 240L Water Capacity With underbody checker plate protection plates with isolator valves
• 120 litre Grey water tank
• 1 X 9KG & 1 X 4.5KG Gas Bottle Holders on slide
• 2x 20L Jerry Can Holders
• Seaflo Mains Water Site Connection
• Drawbar mounted tap
• Front Storage Locker with BBQ Slide ( Dimensions: L 795mm X W 470mm X H 495mm)
• Large Fridge Slide in tunnel -L 980mm X W 530mm X H 555mm)
• Pantry storage box with hinged lid on awning side
• Antenna with points internal & external
• Recovery trax mounted to front of toolbox
• Large lockable tool box with slide with tie down points & Gas strut slow open  auto lid
• Snake trail system over anderson plug for wire protection in tunnel
• Tunnel Door Fridge fan
• Hot and Cold hoses permanently connected to external kitchen in snake protection
• 2 x burner cooktop/induction/or no option available and hot and cold sink with covers
• Composite Aluminium Body Panels
• 12” Electric Brakes with Breakaway System
• External picnic table with storage and charging usb , antenna point, tv bracket
• External handle light with bug light
• Aussie traveller triple locking mechanism door with safety and midgee mesh
• LED light in the internal step
• Rear Lockable Bumper with spare tyre holder, long pole storage and rear lockable toolbox
• Spare wheel bag cover
• Rear Spotlight
• Reverse camera
• Rock sliders
• Cassette toilet
• Instant hot water
• Mains water supply inlet
• Dust reduction 12v with filter
• Under bed storage area on non awning side slide out storage large single long box
• Under bed storage area on non awning side with double slide out metal drawers
• External LED lights (door side + front & rear) with bug function
• External Colour choice of decal
• Hard Roof (ELECTRIC POP UP ROOF AVAILABLE)

• Queen Plush Pillow Top Inner Spring Mattress (Central walk around island bed or to the side options)
• Long external drawers on steel runners under bed
• Large Underbed Storage Drawers X2
• Full ensuite with separate shower & toilet plus vanity basin
• Double-glazed windows with inbuilt privacy & fly screens & blockout blinds
• LED Skylight hatches
• L Shape Lounge with swivel table (removable)
• Solid door  to ensuite with full length mirror
• Storage large pockets on wall & above main door
• Backlit bathroom mirror
• Towel Rail
• Seperate shower with frosted glass door & removable shower head
• Bedside cupboards hanging or shelving choice (if have walk around)
• Sink with chopping board
• Rangehood
• Hooks
• Roof vent above toilet and shower
• Choice of colours for cabinets, stickers, flooring ask your sales person

• Washing machine 2.5kg
• Internal Dometic 2 burner cooktop/induction double/induction single/ or no inbuilt and portable induction options available and sink
• Stainless Steel slide out External kitchen Dometic 2 burner cooktop and sink iwth hinged chopping board shelf including cutlery drawr
• Webasto Cool Top Trail 24 Reverse Cycle Heating & Cooling
• Arana Constant Gas Hot Water System
• Bluetooth stereo, USB and FM Radio Audio System with Indoor/ Outdoor Speakers
• 157L Upright Compressor Fridge/Freezer
• External kitchen Stainless Steel slide out Dometic 2 burner cooktop and sink
• Microwave
• 15 amp inlet
• Diesel heater
• Double gas burner inside (induction option available)
• TV including bracket and straps for travel

• 5 x 200w (1000W in total) Solar Panels
• Internal LED lights
• External Dual Colour LED Lighting
• LED Bedside Reading Lamps
• Multiple 12V and USB-A & USB-C Power Sockets
• Multiple 240V Double Power-Points Throughout
• 12v Fans each side of bed
• 2x 300ah  Lithium Battery (add additional 300ahOptional)
• Renogy Pure Sine Wave 3000w Inverter
• REDARC Manager 50 Battery Management System
• External & Internal  TV box with powered TV connections
• Roof mounted antenna
• Wireless mobile charging points next to bed
• 240 + USB charging in nook beside bed
• Beside reading lights
• Ambient strip light with mains switch also beside bed

• External Dual Zone Fridge/Freezer – $2,050
• Evakool 95L fridge $1600
• My Coolamn 95L Fridge $1600
• Looseal Toilet $2600
• OGO Compost Toilet $2300
• Suspension Upgrades
• Lovells Upgrade Shocks/Springs – $1,600- single axel
• Lovells Upgrade Shocks/Springs - $2400 dual axel
• ATX Air Bag suspension self-Levelling sdual axel – $20,000
• Power Upgrades
• Renogy 3000W inverter Upgrade $1000
• RedArc 3000W Inverter A/C Transfer $3,300
• Extra 300ah  Renogy Lithium Battery $1,500 each can have up to 900ah
• RedArc Management Upgrade
• Alpha 50 with shunt – $3,000
• Alpha 75 with shunt – $ 3,200
• Alpha 100 with shunt – $4,000
• Accessories
• Gas Bayonet $350
• ISI Two Bike Carrier + Drawbar mount – $2,000
• ISI Four Bike Carrier + Drawbar mount -$2,500
• Hose starter package $285
• Black jack mini $655 + $300 Anderson plug
• Black Jack Master $525 + $300 Anderson plug
• Arcmate BBQ $310 fits over spare tyre, Rotisserie & motor, kit $16,  grill $90, bbq plate $85
